Product Detail
15Kg Commercial Freeze Dryer / Lyophilizer NovaDryer-HF1500
Detail
15Kg/Batch Commerial Freeze Dryer / Lyophilizer NovaDryer-HF1500 for Small Food Business
Main Features
One-key start automatic run
User programmable settings for various food
Automatic/Manual dual control modes
USB history curve and data export
SUS304 stainless steel interior and trays
Compressor and vacuum pump protection
Silent and low-heat vacuum pump
PLC controller with color LCD touch screen
Password protection for authorized access
Multiple temperature PT100 sensors
CFC-free refrigerant
Unattended during night
Automatic defrosting
Guaranteed warranty &free lifetime support
Powder coated housing (Optional: stainless steel exterior)
Clear acrylic glass door with direct observation of freeze drying status
Thermostatic heating stainless steel tray and stainless steel chamber reliable for food safety and easy for cleaning
Safety Protection:
Safety voltage,over temperature, over load, over current, protection. Pressure protection. Vacuum leakage detection
Specifications:
| Model | NovaDryer-HF1500 |
| Controller | PLC |
| Display | 4.3”Colour Touch Screen |
| Heating Method | Thermostatic Shelf Heating |
| Freeze Drying Area(㎡) | 1.45 |
| Parameter Memory | 5 groups with max. 18 sections each |
| Defrost | Thermostatic. Programmable. Automatic run. |
| Shelf Qty. (PCS) | 7 (one tray/shelf) |
| Tray Size(WxDxH,mm) | 280x760x20 |
| Shelf Space/Tray Space (mm) | 45/43 |
| Max. Load Capacity(Kg) | 15 |
| Compressor | Single |
| Cold Trap Temperature(℃) | -60(RT<25℃) |
| Vacuum Pump Type | Direct-drive Rotary Vane Oil Vacuum Pump |
| Vacuum Pump Oil | ISO Viscosity Grade 46 or 68 |
| Temperature Sensor | PT100 |
| Extreme Vacuum Degree(Pa) | 10 |
| Refrigerant | Mixed Refrigerant |
| Chamber/Tray Material | SUS304 (Optional: SS316) |
| Exterior Material | Powder coated mild steel (Optional: SUS304) |
| Total Power(Kw) | 6 |
| Power Consumption (Kw/Hr) | 4.2 |
| Environmental Temperature | 10℃-30℃ |
| Dimensions (WxDxH,mm) | 720x1050x1100 |
| Packing Size(WxDxH,cm) | 820x1150x1250 |
| N.W.(main unit) /G.W. (Kg) | 170/250 |
| Power Supply | Standard: AC380V/50Hz or 60Hz,3 phase. 20A (Option 1: AC380V/60Hz,3 phase. Option 2: .AC220V/50Hz,3 phase. Option 3: AC220V/60Hz,3 phase) |
| Standard Configuration | USB data export interface,1x premium oil vacuum pump MegaMax-24, 7x SUS304trays,1xvacuum hose,2xKF25 connectors,2 fuses |
| Optional Accessory | Vacuum pump inlet filter, vacuum pump outlet filter, manual vacuum ball valve, drip tray |
